Network Instructions
Description
Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing using
Index Registers
Sends the "read information/status" explicit message command (stored in
words S+1 to S+3) to the node address specified in S, via the Communica-
tions Unit with the FINS unit address specified in bits 00 to 07 of C+1.
When the response to the explicit message is received, the response's ser-
vice data (data following the service code) is stored in the range of words
beginning at D+1.
The number of bytes of received data indicated in D is the number of bytes of
service data. (For example, if there is 1 byte of service data, D will contains
0001 hex. D will contain 0001 hex regardless of the byte order setting, i.e.,
whether the byte is stored in the rightmost or leftmost byte of D.)
The setting in bits 12 to 15 of C+1 (0 or 8 hex) determines the byte-order of
the service data stored at S+6 and D+3.
• Storing Data from the Leftmost Byte
Set bits 12 to 15 of C+1 to 0 hex.
Frame (order of data in line)
S
C0000 to C4092 C0000 to C4095
D00000 to D00000 to
D32764 D32767
E00000 to E00000 to
E32764 E32767
En_00000 to En_00000 to
En_32764 En_32767
(n = 0 to C) (n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767 (n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767 (n = 0 to C)
---
---
---
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
A B C D
Data
Stored from leftmost byte.
area
15 08 07
D+1 A B
D+2
C D
Note: A, B, C, and D represent bytes of data.
Section 3-25
D C
C0000 to C4092
D00000 to
D32764
E00000 to
E32764
En_00000 to
En_32764
(n = 0 to C)
00
1077
