CJ-series Instruction Execution Times and Number of Steps
Instruction Mne- Code
monic
DOUBLE BDSL 473
SIGNED
BINARY TO
BCD
GRAY GRY 474
CODE
CONVER-
SION
(See note
2.)
FOUR- STR4 601
DIGIT NUM-
BER TO
ASCII
EIGHT- STR8 602
DIGIT NUM-
BER TO
ASCII
SIXTEEN- STR16 603
DIGIT NUM-
BER TO
ASCII
ASCII TO NUM4 604
FOUR-
DIGIT NUM-
BER
ASCII TO NUM8 605
EIGHT-
DIGIT NUM-
BER
ASCII TO NUM16 606
SIXTEEN-
DIGIT NUM-
BER
Note
Length ON execution time ( s)
(steps)
CPU6@ CPU6@
(See
H-R H
note.)
4 7.6 8.1
6.7 8.2
6.7 8.3
6.9 8.8
4 46.9 46.9
49.6 49.6
57.7 57.7
61.8 61.8
64.5 64.5
72.8 72.8
52.3 52.3
55.1 55.1
64.8 64.8
3 13.79 13.79
3 18.82 18.82
3 30.54 30.54
3 18.46 18.46
3 27.27 27.27
3 52.31 52.31
1. When a double-length operand is used, add 1 to the value shown in the
length column in the following table.
2. Supported only by CPU Units Ver. 2.0 or later.
CPU4@ CPU4@ CJ1M
H exclud-
ing
CPU11
/21
8.4 11.6 11.4
8.6 11.8 11.7
8.7 12.0 11.8
9.2 12.5 11.9
72.1 --- 80.0
75.2 --- 83.0
87.7 --- 95.9
96.7 --- 104.5
99.6 --- 107.5
112.4 --- 120.4
87.2 --- 88.7
90.4 --- 91.7
98.5 --- 107.3
20.24 --- 22.16
27.44 --- 29.55
44.41 --- 48.16
27.27 --- 29.13
40.29 --- 42.69
78.25 --- 82.21
Section 4-2
Conditions
CJ1M
CPU11
/21
12.5 Data format
setting No. 0
12.73 Data format
setting No. 1
12.8 Data format
setting No. 2
13.0 Data format
setting No. 3
71.2 8-bit binary
75.6 8-bit BCD
86.4 8-bit angle
91.6 15-bit binary
96.1 15-bit BCD
107.3 15-bit angle
82.4 360 binary
86.8 360 BCD
98.1 360 angle
19.88 ---
26.70 ---
44.10 ---
26.88 ---
39.71 ---
74.23 ---
