CS-series Instruction Execution Times and Number of Steps
4-1-9 Symbol Math Instructions
Instruction Mnemonic
SIGNED +
BINARY
ADD WITH-
OUT
CARRY
DOUBLE +L
SIGNED
BINARY
ADD WITH-
OUT
CARRY
SIGNED +C
BINARY
ADD WITH
CARRY
DOUBLE +CL
SIGNED
BINARY
ADD WITH
CARRY
BCD ADD +B
WITHOUT
CARRY
DOUBLE +BL
BCD ADD
WITHOUT
CARRY
BCD ADD +BC
WITH
CARRY
DOUBLE +BCL
BCD ADD
WITH
CARRY
SIGNED –
BINARY
SUBTRACT
WITHOUT
CARRY
DOUBLE –L
SIGNED
BINARY
SUBTRACT
WITHOUT
CARRY
SIGNED –C
BINARY
SUBTRACT
WITH
CARRY
DOUBLE –CL
SIGNED
BINARY
SUBTRACT
WITH
CARRY
Code Length
(steps)
CPU-6@H CPU-4@H
(See note.)
400 4 0.18
401 4 0.32
402 4 0.18
403 4 0.32
404 4 8.2
405 4 13.3
406 4 8.9
407 4 13.8
410 4 0.18
411 4 0.32
412 4 0.18
413 4 0.32
ON execution time ( s)
CPU-6@ CPU-4@
0.20 0.25 0.37
0.34 0.42 0.54
0.20 0.25 0.37
0.34 0.42 0.54
8.4 14.0 14.0
14.5 19.0 19.0
9.1 14.5 14.5
15.0 19.6 19.6
0.20 0.25 0.37
0.34 0.42 0.54
0.20 0.25 0.37
0.34 0.42 0.54
