Omron SYSMAC CJ - REFERENCE MANUAL 01-2008 Reference Manual page 1240

Block Programming Instructions
Variations
Applicable Program Areas
Operand Specifications
Description
Variations Always Executed in Block Program
Block program areas
OK
Note EXIT(806) and EXIT NOT(806) must be used in block programming regions
even within subroutines and interrupt tasks.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
Task Flags
Condition Flags
Clock Pulses
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
Operation without an Operand
EXIT(806) can be executed without an operand. If it is, then an execution con-
dition must be created for it starting with LD. If the execution condition is OFF,
the rest of the block program will be executed normally. If the execution condi-
tion is ON, the rest of the instructions in the block program through
BEND(801) will not be executed.
Step program areas Subroutines
OK OK
CIO 000000 to CIO 614315
W00000 to W51115
H00000 to H51115
A00000 to A44715
A44800 to A95915
T0000 to T4095
C0000 to C4095
TK0000 to TK0031
ER, CY, >, =, <, N, OF, UF, >=, <>, <=, ON, OFF, AER
0.02 s, 0.1 s, 0.2 s, 1 s, 1 min
---
---
---
---
---
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Section 3-32
EXIT(806)
EXIT(806)
EXIT NOT(806) B
Interrupt tasks
OK
B
1201
B
