Unit Version Notation on Products
Loop Control Boards
Functional Element Name and Version Code for Process-control CPU Units and
Loop-control CPU Units
viii
A "unit version" has been introduced to manage CPU Units, Special I/O Units,
and Inner Boards in the CS/CJ Series according to differences in functionality
accompanying upgrades. This system applies to Units manufactured since Oc-
tober 1, 2003. The unit version code is provided on the nameplate of the product
for which unit versions are being managed, as shown below for the Loop Control
Board.
Loop Control Board
Product nameplate
The CX-Process Tool can be used to confirm the unit versions of Loop Control
Boards in the Monitor Run Status Window. After connecting the CX-Process
Tool online, select Operation – Monitor Run Status from the Execute Menu.
Confirm the unit version in ITEM099 (MPU/FROM version display) under from
the System Common Block (Block Model 000) in the Monitor Run Status Win-
dow.
ITEM
099
The functional element name and functional element version code for Process-
control CPU Units and Loop-control CPU Units are provided on the nameplate
as shown in the following diagrams.
Unit version
Example for unit version 1.5
Data name
MPU/FROM version indication V1.50
Version V1.50 and onwards must be indicated.
Data
