User Link Tables
CX-Process Tool Version
3.2 or Lower
Transferring User Link Tables
Expansion Functions for CX-Process Tool Ver. 5.0 or Higher
1, 2, 3...
168
numbers cannot be downloaded in a batch if the entry numbers are not arranged
beforehand. Always arrange the entries (right-click and select Arrange Num-
ber) before downloading.
Entry numbers are always in ascending order. When an entry is deleted, the
entry numbers are automatically reassigned in ascending order.
The restrictions in the following table apply to user link table selection and trans-
fer using the CX-Process Tool in combination with a Loop Controller (LCBjj).
Additions and deletions are not possible while the Loop Controller is in operation
when using a combination of the CX-Process Tool Ver. 4.0 or higher and LCB-
jj Ver. 2.0 or later. Other combinations require the transfer of LCB/LCB ele-
ments when entries are added or deleted. (The Loop Controller will stop operat-
ing when the LCB/LCB elements are transferred)
Selection and Transfer Capabilities according to the Version of the CX-
Process Tool and Loop Controller
CX-Process LCB Ver. 2.0 or later
Tool Version
Ver. 4.0 or • Selected entries can be trans-
higher
ferred and deleted while the
Loop Controller is in operation.
Ver. 3.2 or • Selected entries cannot be
lower
transferred or deleted during
operation.
• LCB/LCB elements must be
transferred when entries are
added and deleted.
Expansion function must be set when using user link table expansion functions
supported by LCBjj Ver. 3.0 or later. Select the entry in the user link table for
which the expansion functions are to be set. Editing can be performed by right-
clicking and selecting Edit – Extension from the pop-up window. For informa-
tion on each function, refer to the Loop Control Boards Operation Manual (Cat.
No. W406).
The following functions can be set as expansion functions for LCBjj Ver. 3.0.
MV Tight Shut
MV tight shut settings are made in user link tables for output attributes.
1. Right-click the entry for the output attribute (i.e., Wr) and select Edit – Ex-
tension from the pop-up window.
Section
LCB Ver. 1.5 or earlier
• Selected entries cannot be
transferred or deleted during
operation.
• LCB/LCB elements must be
transferred when entries are
added or deleted.
• An Arrange Number operation
is required for entries when
LCB/LCB elements are trans-
ferred to the Loop Controller.
• Selected entries cannot be
transferred or deleted during
operation.
• LCB/LCB elements must be
transferred when entries are
added and deleted.
3-5
