Time And Date - ADC Release 3.1 User Manual

1152700 Issue 1 February 2001 Section 2 Operations and Maintenance
DLP-707
Page 1 of 3
Summary: This procedure describes the steps required to set the system clock at the NMIC in
the Gateway Network Element (GNE). The NMIC maintains the system clock for the entire
network and supports requests from the system administrator to change the system clock. The
NMIC synchronizes every NE's time-of-day clock to the NMIC time-of-day clock.
1. Using the left mouse button, select the Configuration pull down menu, and then select the
first item Time and Date (or hit Alt+C, and Alt+D).
2. Select either Absolute (Alt+A) or Relative (Alt+R) and go to the appropriate heading
below. Refer to Figure
Note: Absolute allows the user to set the time and date to the absolute time specified.
This is needed for turn-up or instances when the clock is more than an hour off. Relative
allows the user to adjust the clock in seconds either forward or backwards, up to one
hour, when smaller adjustments are needed.
Absolute
3. The NMIC Absolute Time Change window appears. See
4. The currently provisioned date and time are displayed. To change any of these parameters,
use the left mouse button to select the current month, day of the week, year, hour, minute,
and second by clicking on the up or down arrows beside each data field.
5. After all selections have been made, select Apply.
6. Select Refresh to update the new date and time displayed in the window. The new time
information is automatically downloaded to each NE.
7. Select Close to return to the Cellworx Vision screen.
Stop! You have completed this procedure.
Relative
8. The NMIC Relative Time Change window appears. See
9. The local time and GMT (Greenwich Mean Time) are displayed. To adjust the current local
time, enter the number in seconds from 1 to 3600 (1-hour) that the clock needs to be
adjusted.
10. Select either backward or forward to adjust the time appropriately.
11. Select Apply to send the new data and adjust the clock.
Page 2-78
© 2000, ADC Telecommunications, Inc.

TIME AND DATE

707-1.
Figure 707-2.
Figure 707-3.
