Summary: This procedure describes the steps required to successfully add, delete, or modify
user access to the Cellworx STN shelf. The user account specifies the name, password, and
access level for the system software which defines what the user can or cannot do while logged
into the shelf. The user account is only active on the shelf it is created on, so it must be
duplicated for each node within the network if the user is to have access to the entire network.
The administrator whom assigns the users must have the highest level of access, which is a level
3 user, to enable administrative duties. Only one administrator should have access to this level at
a time. It is assumed that the Administrator has already gained access to the system and has
launched the Cellworx Vision GUI interface.
1. From the GUI main display, select the node desired by double clicking on it using the left
mouse button.
2. The shelf level "Chassis View" display appears as shown in Figure 768-1.
3. Select the Security pull down menu by clicking on it using the left mouse button.
4. Select the Craft User Configuration option by clicking on it using the left mouse button.
5. The Craft User Configuration window appears as shown in Figure 768-2. Use the up and
down arrow to toggle the user ID field from 1 to 25, selecting the ID number to be assigned
to a user on this node.
Note: Up to 25 users may be assigned per node but only one may be active on a node at a
time.
6. At the User Name field, enter a unique name for the user being assigned. Up to 10
alphanumeric characters may be used.
7. At the Password field, enter a unique password assigned to the user entered above, using at
least 6 and up to 10 characters with at least one character being a numeric value and one
being a special character (dot, dash, etc.).
8. At the Password Verify field, re-enter the password to confirm the password chosen. If the
password is not entered exactly as it was above, the system will not create the user account.
9. At the Days Remaining for Account field, enter the number of days the account will be
allowed to be active. The administrator may wish to re-establish the accounts on a yearly
basis for full time users, or create a temporary account for a few days or a week for a
maintenance person to have temporary access. The accounts can be activated up to 999
days or left at 0 so the account will never expire.
10. At the Privilege Level field, select the Level number, from one to three, that corresponds to
the level of access the user may have. The levels are defined in Table 768-1.
