39. The user may delete a connection, or multiple connections, by selecting them using the left
mouse button, and then selecting Delete. A confirmation message will appear requiring the
user to select OK or Cancel. If a problem exists with the hardware between the NMIC and
the endpoint shelf controllers, a denial message may appear detailing why the connection
could not be deleted. Refer to
40. To gain status information of a certain connection, the user double clicks on the connection
using the left mouse button, or single clicks to highlight the connection followed by
selecting Status at the bottom left of the window.
41. The Connection Status window appears similar to the one shown in
connection name is displayed at the top of the window. The administrative state may show
as Locked or Unlocked. Locked indicates the connection is taken down at both ends, no
traffic is allowed on the ring. Unlocked indicates the connection is operable in a normal
state. The user may change options on the connection by selecting Configure. Access to the
Configure screen can also be obtained from the previous Connection List screen via the
Configure selection button found there.
42. The Connection Configuration screen appears. Refer to
connection name is displayed at the top of the window. The Root end of the connection can
be taken down by changing the Administrative State to Locked using the button at the top
right corner of the window and then selecting Apply. Similarly, the leaf endpoint can be
locked using the feature at the bottom left of the screen.
43. Either or both ends of the connection can be configured as OAM cell segment endpoints by
selecting the Segment Endpoint box displayed at each section of the screen. This
functionality can be used for maintenance or troubleshooting purposes. Select Apply to
send configuration changes to the database or close to abort any changes.
44. The "Configuration Change Completed" window appears. Select OK.
45. Leaves may be added to the connection using the Add Leaf button at the bottom of the
screen. Refer to DLP-791
Stop! You have completed this procedure.
1152700 Issue 1 February 2001 Operation and Maintenance
DLP-713 and the trouble log for any error reports.
to add a leaf to an existing connection.
DLP-790
Page 6 of 14
Figure 790-12. The
Figure 790-13. Again the
Page 2-397
