ADC Release 3.1 User Manual page 166

1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
DLP-726
Page 4 of 4
MONITOR TYPE
CV-L 16383
CV-LFE 16383
ES-L 900
ES-LFE 900
SES-L 900
SES-LFE 900
UAS-L 900
UAS-LFE 900
CV-P 16383
CV-PFE 16383
ES-P 900
ES-PFE 900
SES-P 900
SES-PFE 900
UAS-P 900
UAS-PFE 900
Page 2-146
2000, ADC Telecommunications, Inc.
Table 726-1. SONET Layer PM Values, continued
LINE
Line Code Violation, count of BIP errors detected at the Section layer using the B2
byte in the incoming SONET signal
Far-end Line Code Violation, a count of BIP errors detected at the far end LTE and
reported back to the near end LTE using the Remote Error Indicator (REI) in the
Line overhead
Line Errored Seconds, number of seconds in which at least one Line layer BIP, or an
AIS condition was detected
Far-end Line Errored Seconds, count of the seconds in which at least one Line BIP
was detected by the far end LTE or an RDI-L defect was present
Line Severely Errored Seconds, a count of seconds in which a set number of Line
layer BIP errors, or an AIS condition were detected
Far-end Line Severely Errored Seconds, a count of seconds in which a set number of
Line layer BIP errors, or AIS were detected by the far end LTE
Line Unavailable Seconds, a count of seconds in which the Line was considered
unavailable
Far-end Line Unavailable Seconds, a count of seconds in which the Line was
considered unavailable, reported by the far end LTE to the near end LTE using the
RDI in the Line overhead
PATH
Code Violation, a count of BIP errors detected at the Path layer using the B3 byte of
the incoming SONET signal
Far-end Path Code Violation, a count of BIP errors detected at the far end LTE and
reported back to the near end LTE using the Remote Error Indicator (REI) in the
Path overhead
Path Errored Seconds, number of seconds in which at least one Path layer BIP,
Alarm Indication Signal (AIS), or Loss Of Pointer (LOP) condition was detected
Far-end Path Errored Seconds, count of the seconds in which at least one Path layer
BIP was detected by the far end LTE or an RDI-P defect was present
Path Severely Errored Seconds, a count of seconds in which a set number of Path
BIP errors, AIS, or LOP were detected
Far-end Path Severely Errored Seconds, a count of seconds in which a set number of
Path layer BIP errors, AIS, or LOP were detected by the far end LTE and reported
back to the near end LTE using the RDI-P bit in the Path overhead
Line Unavailable Seconds, a count of seconds in which the Line was considered
unavailable
Far-end Path Unavailable Seconds, a count of seconds in which the Path was
considered unavailable, reported by the far end LTE to the near end LTE using the
RDI in the Path overhead
COMMENTS
