Install the other optional devices

1. Install the optional devices (Document
finisher, Fax kit, etc.) as required.

Release the scanner lock

1. Remove two scanner lock cover using the
flatscrew driver.
2. Reverse the upper and lower sides of a
scanner lock cover and then refit it.
* : Releases the lock of the scanner unit.
* : If a lock is not released, when a power
supply is switched on, an error mes-
sage (C3100) will be displayed.
Scanner lock
cover
[Locked]
1-2-11
Scanner lock
cover
Flat screw
driver
Figure 1-2-17
2NP
[Released]
