Unpacking - Kyocera TASKalfa 2551ci Service Manual

l

Unpacking

10
7
1. Skid
2. Hinge joints
3. Bottom pad RF
4. Bottom pad RR
5. Bottom pad LF
6. Bottom pad LR
7. Bottom pad C
8. Poly bag
9. Accessory box
Cautions: Place the machine on a level surface.
14
16
12
15
20
2
5
1
8
2
Figure 1-2-2
10. Pad F
11. Pad R
12. Stay
13. Outer case
14. Top pad
15. Machine
16. Pad LF
17. Installation guide, etc.
18. Poly bag
12
13
12
12
2
6
4
2
3
19. Power cord
20. Desiccant
