Item No.
U340

Setting the applied mode

Description
Allocates memory to ensure that there is sufficient memory available for the printer to use as a
working area.
Purpose
Modify the memory allocation if insufficient memory for transparency support or XPS direct print-
ing occurs.
Method
1. Press the start key.
2. Select the item to set.
Adj Memory
Adj Max Job
Setting: [Adj Memory]
1. Change the setting using the +/- keys or numeric keys.
Display
Set the values below in case print failure occurs with the memory shortage.
(recommended value)
Image : +100
2. Press the start key. The value is set.
3. Turn the main power switch off and on. Allow more than 5 seconds between Off and On.
Supplement
The work area for copy is small and it may cause output failure if the values are large.
Setting: [Adj Max Job]
1. Change the setting using the +/-keys or numeric keys.
Display
Copy
Printer
The maximum Printer jobs should be (maximum jobs) – (maximum copy jobs).
2. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Display
Setting the memory allocation
Setting the maximum of multiple jobs
Area temporarily used to create output
image.
Maximum copy (Scan To Print) Jobs
Maximum printer (Host To Print) Jobs
Description
Description
Description
Description
1-3-125
Setting Initial
range setting
-100 to 100 0
(MB)
Setting Initial
range setting
10 to 50 10
10 to 50 -
