Item No.
U404

Adjusting margins for scanning an original from the DP

Description
Adjusts margins for scanning the original from the DP.
Purpose
Perform the adjustment if margins are incorrect.
Caution
Before making this adjustment, ensure that the following adjustments have been made in mainte-
nance mode
U402
( P.1-3-129)
Adjustment
1. Press the start key.
2. Press the system menu key.
3. Place an original on the DP and press the start key to make a test copy.
4. Press the system menu key.
5. Select the item to be adjusted.
Display
A Margin
B Margin
C Margin
D Margin
6. Change the setting value using the +/- keys or numeric keys.
Increasing the value makes the margin wider, and decreasing it makes the margin narrower.
7. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Description
U403
( P.1-3-130)
Description
DP left margin
DP leading edge margin
DP right margin
DP trailing edge margin
DP leading edge margin
(3.0 ± 1.5 mm)
DP
left margin
(2.0 ± 1.0 mm)
DP trailing edge margin
(2.0 ± 1.0 mm)
Figure 1-3-38
1-3-131
U404
Setting
range
0 to 10.0
0 to 10.0
0 to 10.0
0 to 10.0
DP right margin
(2.0 ± 1.0 mm)
Initial Change in
setting value per step
3.0 0.5 mm
2.5 0.5 mm
3.0 0.5 mm
4.0 0.5 mm
