Item No.
U243

Checking the operation of the DP motors

Description
Turns the motors or solenoids in the DP on.
Purpose
To check the operation of the DP motors and solenoids.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
Feed Motor
Conv Motor
Rev Motor
Lift Motor
Rev Press Sol
Rev Branch Sol
Eject Motor
Regist Motor
DP Fan
CIS Fan
: DP-770(B)
*1
4. To turn each motor off, press the stop key.
Completion
Press the stop key when operation stops. The screen for selecting a maintenance item No. is dis-
played.
Display
*1,*2,*3 DP original feed motor (DPOFM) is turned on
*1,*2 DP original conveying motor (DPOCM) is turned on
*1,*3 DP switchback motor (DPSBM) is turned on
*1,*2 DP lift motor (DPLM) is turned on
DP pressure solenoid (DPPSOL) is turned on
*1
*1 DP feedshift solenoid (DPFSSOL) is turned on
*2 DP eject motor (DPEM) is turned on
*2 DP registration motor (DPRM) is turned on
*2 DP fan motor 1 (DPFM1) is turned on
*2 DP fan motor 2 (DPFM2) is turned on
: DP-772 : DP-773
*2 *3
Description
Description
1-3-107
2NP
