7. Press the start key. Auto adjustment starts.
U411
* : When automatic adjustment has normally completed, [OK] is displayed. If a problem
occurs during auto adjustment, error code is displayed and operation stops. Should this
happen, determine the details of the problem and repeat the procedure from the begin-
ning.
Method: [DP FaceDown (Chart2)]
1. Place the specified original for acquiring gamma target data (P/N: 303JX57010) on the
platen, and press the start key.
2. Place the specified original for acquiring matrix target data (P/N: 303JX57020) on the platen,
and press the start key.
When normally completed, [OK] is displayed.
3. Select the item.
Display
All

Input

MTF/Gamma
Matrix
[Input]
1. Select [Input].
2. Set a specified original (P/N: 302AC6824) on the DP face down.
3. Press the start key. Auto adjustment starts.
[MTF/Gamma]
1. Select [MTF/Gamma].
2. Set a specified original (P/N: 303JX57010) on the DP face down.
3. Press the start key. Auto adjustment starts.
[Matrix]
1. Select [Matrix].
2. Set a specified original (P/N: 303JX57020) on the DP face down.
3. Press the start key. Auto adjustment starts.
When [ALL] is selected, the adjustment of [Input], [MTF/Gamma] and [Matrix] can be executed at
once. When adjusting, place the three specified originals on the DP face down, and then press
the start key.
Set the original 303JX57020, and then place 303JX57010 and 302AC68243 in order on the top
of the original.
Description
Description
Executing the adjustment in the DP scan-
ning section (second side) for magnifica-
tion, leading edge timing, center line, MTF
filter, input gamma and matrix
Executing the adjustment in the DP scan-
ning section (second side) for magnifica-
tion, leading edge timing and center line
Executing the adjustment in the DP scan-
ning section (second side) for MTF filter
and input gamma
Executing the adjustment in the DP scan-
ning section (second side) for matrix
(When there is no Chart 2 (302AC68243),
it performs in simple.)
1-3-138
2NP-3
Original to be used
for adjustment (P/N)
302AC68243/
303JX57010/
303JX57020
302AC68243
303JX57010
303JX57020
