Chapter 3

SPC TWINAX SETUP

SPC TWINAX SETUP
SPC TWINAX
1, 2, 3
SETUP
(from page 97)
SPC Type SFCC Char
MODE PTX NI* User Defined
MODE 219 Set 1 <%>*
MODE P5000 Set 2 ^^$
MODE IBM Set 3 _%_
Translation Buffer
Tbl Print
Disable*
Enable
170
User User
4
Defined St1 Defined St2
5F* 5F*
40 to FF 40 to FF
Notes:
* = Factory Default
1
This menu appears only if the CTHI option is installed.
2
This menu appears only if Port Type (under C/T PORT) is set to Twinax.
3
Appears only if CTHI emulation (under PRINTER CONTROL) is set to Simp
Prot Conv.
4
This menu appears only if you select the "User Defined" option in the "Lead-in
Chars" menu.
User SPC
4 4
Defined Stp Char Set
5B*
0500 Internat 5*
40 to FF
0037 English US
0273 Austr/Germ
0274 Belg. Old
0275 Brazilian
0260 Canad Fren
0277 Danish
0278 Finnish
0297 French
0280 Italian
0281 Japan. Eng
0290 Japan Kata
0282 Portuguese
0284 Span Speak
0285 English UK
