Printronix SL5000 User Manual page 102

Chapter 3
Main Menu
EPSON FX
3, 4, 5
SETUP
(page 191)
Select CPI
Select LPI
Typeface
Character Group
Character Set
Epson Set
Horizontal DPI
Vertical DPI
Prop. Spacing
Italic Print
Slashed Zero
5
Left Margin
5
Right Margin
Top Margin
Bottom Margin
Print Char. Set
Define CR code
Auto LF
Define LF code
Printer Select
20 CPI Condensed
Bold
Alt. Set 80-9F
Text Position
Host Command
Reset Cmd CFG Ld
Form Length (inches)
5, 6
Form Length (mm)
5
Form Length (lines)
5, 7
Form Width (inches)
5, 7
Form Width (mm)
5
Form Width (char.)
NOTES:
Italicized items are available only when Admin User is set to Enable (in the PRINTER CONTROL menu).
1
Available only when the Centronics option is set to Enable (in the Port Type submenu of PARALLEL
PORT).
2
Menu shown only if Feature File has been loaded.
3
Available only when Admin User is set to Enable (in the PRINTER CONTROL menu).
4
The presence of this menu depends on the LP+ Emulation selection (under PRINTER CONTROL).
5
These menus do not display when CT, TN5250, or TN3270 emulation is selected.
6
All three Form Length submenus work in conjunction. When you change the default in one submenu, the
default value in the other two submenus change automatically.
7
All three Form Width submenus work in conjunction. When you change the default in one submenu, the
default value in the other two submenus change automatically.
102
DIAGNOSTICS
(page 237)
Printer Tests
Test Count
Software Build
2
Feature File
Hex Dump Mode
Print Error Log
Clear Error Log
FLASH Installed
DRAM Installed
Ptr On Time
Ptr Media Dist
Head Print Dist
Head On Time
Reset Head Data
Head Type
Head Voltage
5, 6
PARALLEL
PORT
(page 241)
Port Type Port Type
1
Data Bit 8 Baud Rate
1
PI Ignored Word Length
Buffer Size in K Stop Bits
Auto Trickle Parity
Trickle Time Data Protocol
Timeout Buffer Size in K
Report Status Trickle Time
Switch Out On Timeout
Prime Signal Report Status
1
Data Polarity Data Term Ready
1
Resp. Polarity Request to Send
1
Busy on Strobe Poll Character
1
Latch Data On Poll Response
Offline Process Idle Response
One Char Enquiry
Printer Status
Framing Errors
Offline Process
SERIAL
PORT
(page 245)
