Physical

Outside Dimensions (in.)
Weight (lbs/kg)
Add 1.75" D with media guide installed
Add 7.5" D and 6" H for validator option
Add 1.4" D for media cutter option

Acoustic Specifications

Table 30. T5000 Acoustic Noise Levels per ISO 9296
Printing @ 6 IPS
Standby:

Maximum Page Length

The maximum page length allowed is dependent on the following factors:
•
The DPI of the printhead. 300 DPI uses more memory than 203 DPI,
therefore, 300 DPI printers have a smaller maximum page length than
203 DPI printers.
•
The value of "Label Width" (under the QUICK SETUP or MEDIA
CONTROL menu). As this value increases, the maximum page length
decreases.
•
The value of "Glob Mem Adjust" (under the PRINTER CONTROL menu).
As this value increases, page memory and the maximum page length
decreases. Note that this menu item is independent of a configuration
(that is, it does not need to be saved under a configuration number), and
the printer must be rebooted for it to take effect.
Also be aware that a maximum page length is based on the ability of the
printer to reserve at least one page at the specified length. However, the
printer needs two pages to achieve full throughput. Therefore, maximum page
lengths less than 99 inches should be divided in half when considering
throughput. Maximum page lengths at 99 inches can achieve full throughput
at higher values than 49.5 inches.
Table 29. Physical Dimensions
T5X04
SL5X04 MP2
13H x 11.7W x 13H x 13.4W x
20.5D 20.5D
36.6 lbs. (16.6 kg) 40 lbs. (18.14 kg)
37.2 lbs. (16.87 kg) 40.6 lbs. (18.42 kg)
T5X04
SL5X04 MP2
68 dBA
37 dBA
T5X06
SL5X06 MP2
13H x 15.4W x
20.5D
43 lbs. (19.5 kg)
T5X06
SL5X06 MP2
62 dBA
37 dBA
Physical
T5X08
T5X08
62 dBA
37 dBA
