Chapter 3
MEDIA CONTROL
Print Direction and Orientation are two independent options that can be
combined to produce the following results depending on the Active IGP
Emulation:
Print Direction
Head First
Head First
Head First
Head First
Print Direction
Foot First
Foot First
Foot First
Foot First
The factory default is Head First when IGP/PGL or IGP/VGL is enabled.
The factory default is Foot First when PPI/ZGL is enabled.
Label Wait Time
When Media Handling is set to Tear-Off Strip or Continuous, and Continuous
Mode is set to Tear Strip Full, Label Wait Time specifies the number of
seconds after printing stops that the printer will wait before it advances media
to the tear bar position.
When Media Handling is set to Peel-Off or Tear-Off, Label Wait Time
specifies the number of seconds the printer will wait after a label is removed
from the peel/tear bar before starting to print the next label.
The range is 0.1 to 60.0 seconds, and the factory default is 0.1 second.
130
Table 4. Head First
Orientation Option
Option
Portrait
Landscape
Inv. Portrait
Inv. Landscape
Table 5. Foot First
Orientation Option
Option
Portrait
Landscape
Inv. Portrait
Inv. Landscape
Result in Active IGP Emulations
(IGP/PGL or IGP/VGL)
Portrait
Landscape
Inv. Portrait
Inv. Landscape
Result in Active IGP/ZGL
Emulation
Portrait
Inv. Landscape
Inv. Portrait
Landscape
