Vertical Density
This option is to adjust printer dpi to expand and shrink the vertical position or
the height of the graphic elements. The option is only available for 203 dpi
printers. The default is 203 dpi. The adjustment range is from 195 to 210 dpi.
Vertical DPI
This feature enables the thermal printer to print images as close as possible
to the same size as those originally programmed for a line matrix or laser
printer by selecting a vertical resolution that matches that of the printer that
the file was originally generated for.
Although the range allows a selection of up to 400 dpi, the thermal printer is
capable of printing up to 203 dpi (T5204, T5206, T5208) and 300 dpi (T5304,
T5306, T5308) vertical resolution.
The range is 72-400 DPI, and the factory default is 72 DPI.
VPA Check
•
Enable (the default). The printer checks for dots that fall outside the
intersection of the logical and physical pages. If dots fall outside the area,
the printer reports an error to the host if the IPDS Exception Handling
Control command setting requires error reporting.
•
Disable. The printer does not report dots outside the valid printable area.
Width Limit
When enabled, the system will limit the length and width for expanded
characters to a limit shown in Table 7, which shows the maximum width
allowed for a specific height in the range of 00 through 40 (0.0 through 4.0
inches).
The factory default is Disable.
Table 7. Width Limit Table
Height Max. Width
Param. Allowed
00 99
01 99
02 3
03 6
04 8
05 11
06 13
Emulation Submenus
Height Max. Width
Param. Allowed
21 51
22 53
23 56
24 58
25 61
26 63
27 66
