Chapter 2

Using The Optional Internal Rewinder

9. If you have not run an Auto Calibrate with this media and ribbon, do so
now. See "Running Auto Calibrate" on page 72.
10. Press the FEED key once to verify that the media and ribbon advance.
11. Press the PAUSE key to place the printer online.
12. Close the printer media cover if the rewinder is not needed.
Using The Optional Internal Rewinder
The printer can be set up to rewind labels after they have been printed (Batch
Rewind Mode) or to automatically peel labels from their backing and dispense
them one at a time while rewinding the liner (Peel-Off Mode). Both modes
require an internal rewinder, which is available as a factory installed or a field
unit option.

Batch Rewind Mode

Batch Rewind allows you to automatically rewind printed labels into a roll
using the optional internal rewinder.
Configuring the Printer Menu
1. Set Media Handling to "Continuous" under the QUICK SETUP menu.
(See Chapter 3, "Configuring The Printer" for more information.)
2. Press the PAUSE key until "OFFLINE" displays.
54
