C/T PORT

1
C/T PORT
(from page 102)
Port Type Device
Address
Twinax* Address 1*
Coax Address 0-6
Disable

C/T PORT Submenus

Port Type
This item selects the desired active CTHI interface and appears only when
the CTHI option is installed.
The factory default is Twinax.
Device Address
Allows you to set the device address from 0 through 6. The host directs data
and commands on the twinax line to a specific device based on its unique
device address. After the address has been changed, a Power On Reset
(POR) status is sent to the host.
The factory default is 1.
Timeout
This item allows you to set the time that the printer, when it has not received
data from its host, will begin to service all other host ports looking for data to
print.
The range is from 5 to 60 seconds, and the factory default is 10 seconds.
Report Status
When a fault condition occurs in the printer, normally only the active port
reports the fault to the host. With this item enabled, the port will report any
fault even when it is not the current, active port.
The options are Disable (the factory default) and Enable.
Timeout Report Status
10 sec.* Disable*
5-60 sec. Enable
Notes:
* = Factory Default
1
This menu appears only if the CTHI option is installed.
C/T PORT Submenus
253
