Printing A Configuration

We recommend that you print and store your configurations for future
reference. The printout provides a list of the parameters that were set when
you configured the printer.
To print a configuration:
. .
1. Press the key until the following message displays:
.
MENU MODE
CONFIG. CONTROL
2. Press the ↓ key until the following message displays:
Print Config.
Current*
or − key to cycle through the following printout options:
+
3. Press the
Current*
Factory
Power-Up
All
1-8 customized configurations
4. When the desired option displays, press the ↵ key. The printer prints the
specified configuration.
NOTE: If the configuration you want to print has not been saved, the
following message displays momentarily:
CONFIG. DOES NOT
EXIST/Save First
This message indicates that no configuration menu has been saved
under the configuration value you have selected and therefore cannot
be printed. You must either select another configuration to print or
load and then save a configuration to that configuration value first.

Loading A Saved Configuration

To use a different configuration:
1. Press the PAUSE key until OFFLINE displays.
2. Press the JOB SELECT key until the desired configuration displays.
3. Press ↵. Loading Saved/Configuration displays.
