BMC
way to add, manage and authenticate MegaRAC
This is done by passing login requests to your LDAP Server.
This means that there is no need to define an additional authen-
tication mechanism, when using the MegaRAC card. Since
your existing LDAP Server keeps an authentication centralized,
you will always know who is accessing the network resources
and can easily define the user or group-based policies to con-
trol access.
To open LDAP Settings page, click Configuration > LDAP
from the main menu. A sample screenshot of LDAP Settings
Page is shown in the screenshot below.
LDAP Settings Page
The fields of LDAP Settings Page are explained below.
®
card users.
LDAP Settings Page
Advanced Settings
Add Role Group
Modify Role Group
Delete Role Group
Procedure:
Entering the details in Advanced LDAP Settings Page
1. In the LDAP Settings Page, click Advanced Settings. A
sample screenshot of LDAP Settings page is given below.
2. To enable/disable LDAP Authentication, check or
uncheck the Enable checkbox respectively.
4-24
I
TEM
To configure LDAP Advanced Settings. Options
are Enable LDAP Authentication, IP Address,
Port and Search base.
To add a new role group to the device. Alterna-
tively, double click on a free slot to add a role
group.
To modify the particular role group.
To be delete a role group from the list.
Advanced LDAP Settings
C G
ONFIGURATION ROUP
D
ESCRIPTION
