Compaq StorageWorks
UltraSCSI RAID Enclosure
(DS–BA370 Series)
User's Guide
Part Number: EK–BA370–UG. C02/387403–001
September 1998
The DS–BA370 series UltraSCSI RAID rack-mountable enclosure is the
basic building block of UltraSCSI RAID subsystems. This guide and its
related publications comprise the basic documentation set for these
subsystems.
Compaq Computer Corporation
Houston, Texas
