▼ Connect the SER MGT Port Cable

The service processor serial management port is marked SER MGT. This port is the
farthest left RJ-45 port on the rear panel.
●
Connect a Category 5 cable from the SER MGT serial management port to the
terminal device.
Service Processor Serial Management Port – Rear Panel
FIGURE:
This port is needed to set up the service processor network management port.
When connecting a DB-9 cable, use an RJ-45 to DB-9 adapter to perform the
crossovers given for each connector.
Note – Use the service processor serial management port only for server
management. This port is the default connection between the service processor and a
terminal or a computer.
Caution – Do not attach a modem to this port.
Related Information
"Connect the NET MGT Port Cable" on page 50
■
"Connecting the Server Cables" on page 47
■
