Unlocking the Slide Rail Middle Section
FIGURE:
3. Attach a mounting bracket to the right side of the chassis.
a. Position the mounting bracket against the chassis. Ensure that the slide rail
lock is at the front and the three keyed openings on the mounting bracket are
aligned with the three locating pins on the side of the chassis.
