Rear Panel System LEDs and Button

The following figure shows location of the system LEDs and the locator button on the
rear panel.
FIGURE:
Figure Legend
1
2
18
SPARC T3-1 Server Installation Guide • March 2012
Rear Panel System LEDs
Locator LED and button
Fault - Service Required LED
3
Power OK LED
