Sun Oracle SPARC T3-1 Installation Manual page 17

SPARC T3-1 Server (8-Disk Capacity) Power Specifications (Continued)
TABLE:
Peak input power running SpecJBB
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(16 core, 1.6 GHz processor, with four 2 GB DIMMs, 1 HDD, no PCIe I/O cards)
Idle input power
Peak input power running SpecJBB
SPARC T3-1 Server (16-Disk Capacity) Power Specifications
TABLE:
General Specifications
Operating input voltage range
(input voltage tolerance +/- 10%)
Maximum operating input current at 100 VAC
Maximum operating input current at 200 VAC
Maximum operating input power at 100 VAC
Maximum operating input power at 200 VAC
Maximum heat dissipation at 100 VAC
Maximum heat dissipation at 200 VAC
Maximum standby power
Inrush current (peak)
Leakage current
Maximum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(16 core, 1.6 GHz processor, with sixteen 8 GB DIMMs, 16 HDDs, 6 PCIe I/O cards)
Idle input power
Peak input power running SpecJBB
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(16 core, 1.6 GHz processor, with four 2 GB DIMMs, 1 HDD, no PCIe I/O cards)
Idle input power
Peak input power running SpecJBB
Notes:
582 W
290 W
352 W
Values
100 to 240 VAC,
50-60 Hz
9.4 A
4.7 A
896 W
888 W
3057 BTU/hour
(3226 KJ/hour)
3030 BTU/hour
(3197 KJ/hour)
30 W
25 A
1.6 mA
494 W
678 W
297 W
359 W
Preparing for the Installation 9
