Ethernet ports are labeled NET0, NET1, NET2, and NET3. The Ethernet interfaces
■
operate at 10 Mbps, 100 Mbps, and 1000 Mbps.
TABLE:
Connection Type
Ethernet
Fast Ethernet
Gigabit Ethernet
VGA DB-15 video port: Use the video port to attach a color monitor to the server.
■
USB Ports: USB ports support hot-plugging. You can connect and disconnect USB
■
cables and peripheral devices without affecting system operations.
■
■
Power cables: Do not attach power cables to the power supplies until you have
■
finished connecting the data cables, and have connected the server to a serial
terminal or a terminal emulator (PC or workstation).
Note – The server goes into Standby mode and the Oracle ILOM service processor
initializes as soon as a power cable connects a power suppply to an external power
source. System messages might be lost after 60 seconds if a terminal or terminal
emulator is not connected to the serial management port before power is applied.
Related Information
"Connecting the Server Cables" on page 47
■
48 SPARC T3-1 Server Installation Guide • March 2012
The service processor network management port uses an RJ-45 cable for a
10/100 BASE-T connection. This port does not support connections to Gigabit
networks.
Ethernet Connection Transfer Rates
IEEE Terminology
10BASE-T
100BASE-TX
1000BASE-T
You can only perform USB hot-plug operations while the OS is running. USB
hot-plug operations are not supported when the system ok prompt is displayed
or before the system has completed booting.
You can connect up to 126 devices to each of the four USB controllers, for a total
of 504 USB devices per system.
Transfer Rate
10 Mbit/sec
100 Mbits/sec
1000 Mbit/sec
