Row A
Pin
BIOS_DIS0#
A34
A35 THRMTRIP#
USB6-
A36
USB6+
A37
USB_6_7_OC#
A38
USB4-
A39
USB4+
A40
A41 GND (FIXED)
USB2-
A42
USB2+
A43
USB_2_3_OC#
A44
USB0-
A45
USB0+
A46
A47 VCC_RTC
A48 EXCD0_PERST#
A49 EXCD0_CPPE#
A50 LPC_SERIRQ
A51 GND (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5‑
A54 GPI0
A55 PCIE_TX4+
4.1.1

SM Bus

On the COM Express™ module, the System Management Bus (SMB) is powered by the standby power rail in order to have control over the
system during the system states S0‑S5. The devices on the conga‑CEVAL (e.g. PCI Express clock buffer or PCI Express connectors) using the
SMB are normally powered by the 3.3V main power. To avoid current leakage between the main power of the carrier board and the standby
power of the module, a bus switch separates the SMB on the conga-CEVAL carrier board from the SMB of the module.
The SM Bus signals are available on the feature connector (X27) described in section 5.8.
