Industry Specifications

7
The list below provides links to industry specifications that should be used as reference material when designing a COM Express™ carrier
board.
Specification
COM Express Module™ Base Specification
PICMG ®
PCI Express Base Specification, Revision 2.0
PCI Local Bus Specification, Revision 2.3
Universal Serial Bus (USB) Specification, Revision 2.0
ExpressCard Standard Release 1.0
Serial ATA Specification, Revision 1.0a
Low Pin Count Interface Specification, Revision 1.0 (LPC)
Audio Codec '97 Component Specification, Version 2.3
High Definition Audio Specification, Rev. 1.0
LVDS Owner's Manual
Extended Display Identification Data Standard Version 1.3 (EDID™)
Enhanced Display Data Channel Specification Version 1.1 (DDC)
IEEE standard 802.3ab 1000BASE T Ethernet
Advanced Configuration and Power Interface Specification Rev. 3.0a
The following reference material from Mindshare Books is recommended by congatec AG. For more information and additional books visit www.mindshare.com.
Title
PCI Express System Architecture
PCI System Architecture (4th Edition)
Universal Serial Bus System Architecture
SATA Storage Technology
Protected Mode Software Architecture
(The PC System Architecture Series)
The Unabridged Pentium 4
Additional books covering various PC architecture subjects that should be used as reference material can be found at www.intel.com/intelpress.
Copyright © 2012 congatec AG
Link
http://www.picmg.org/
http://www.pcisig.com/specifications
http://www.pcisig.com/specifications
http://www.usb.org/home
http://www.expresscard.org/
http://www.serialata.org
http://developer.intel.com/design/chipsets/industry/lpc.htm
http://www.intel.com/design/chipsets/audio/
http://www.intel.com/standards/hdaudio/
http://www.national.com
http://www.vesa.org
http://www.vesa.org
http://www.ieee.org/portal/site
http://www.acpi.info/
Author
Ravi Budruk, Don Anderson, Tom Shanley
Tom Shanley, Don Anderson
Don Anderson
Don Anderson
Tom Shanley
Tom Shanley
CEVA_c_m10 47/47
