Fan Connector and Power Configuration
5.6
Configuration
Jumper X63
1 ‑ 2
12 Volt fan (default)
2 ‑ 3
5 Volt fan
Connector Type
X14: 3 pin 2.54mm grid fan connector,
X63: 3 pin 2.54mm grid jumper.
Note
congatec COM Express™ modules provide signals for fan control. This has been implemented through the use of some reserved pins.
COM Express™ module pin C77 provides the FAN_TACHOIN signal that is attached to pin 3 of the fan connector X14 found on the conga-CEVAL.
This signal must receive two pulses per revolution in order to produce an accurate reading and therefore a two pulse per revolution fan is
recommended.
5.7
SMART Battery Management Module
Connector X1 is used to connect the conga-CEVAL to a congatec SMART Battery Management Module evaluation kit. The following table
describes the pinout of the X1 connector.
Pin
Signal
1
I2CLK
PWRBTN#_EXT
3
5
PS_ON#
7
VCC
9
SUS_STAT#
Note
The asterisk (*) indicates that the signal SUS_S45# is a logical ANDing of SUS_S4# and SUS_S5# signals.
Connector Type
X1: 10 pin, 2 row 2.54 mm grid box header.
Copyright © 2012 congatec AG
Pin Signal
2
I2DAT
BATLOW#
4
6
*SUS_S45#
5V_SB
8
10
GND
CEVA_c_m10
Fan Power Config.
Fan
(X14)
3
2
1
SBM²
(X1)
2
4
6
8
1
3
5
7
(X63)
3
2
1
10
9
44/47
