PCI Express Slot 0/Lane 0 Connector X17
Pin Signal
B1
+12V
B2
+12V
B3
N.C.
B4
GND
B5 SMB_CK
B6 SMB_DAT
B7
GND
B8
+3.3V
B9
N.C.
B10
+3.3V Standby
B11
WAKE0#
B12
N.C.
B13
GND
B14
PCIE_TX0+
B15
PCIE_TX0‑
B16
GND
B17
PRSNT#2_S0
B18
GND
PCI Express Slot 2/Lane 3 Connector X45
Pin Signal
B1
+12V
B2
+12V
B3
N.C.
B4
GND
B5 SMB_CK
B6 SMB_DAT
B7
GND
B8
+3.3V
B9
N.C.
B10
+3.3V Standby
B11
WAKE0#
B12
N.C.
B13
GND
B14
PCIE_TX3+
B15
PCIE_TX3‑
B16
GND
B17
PRSNT#2_S2
B18
GND
Copyright © 2012 congatec AG
PCI Express Slot 1/Lane 1 Connector X18
Pin Signal Pin Signal
B1
A1 PRSNT#1_S0 +12V
B2
A2 +12V +12V
B3
A3 +12V N.C.
B4
A4 GND GND
B5 SMB_CK
A5 N.C.
B6 SMB_DAT
A6 N.C.
B7
A7 N.C. GND
B8
A8 N.C. +3.3V
B9
A9 +3.3V N.C.
B10
A10 +3.3V +3.3V Standby
B11
A11 PCIE_RST# WAKE0#
B12
A12 GND N.C.
B13
A13 PCIE_CLKS0+ GND
B14
A14 PCIE_CLKS0‑ PCIE_TX1+
B15
A15 GND PCIE_TX1‑
B16
A16 PCIE_RX0+ GND
B17
A17 PCIE_RX0‑ PRSNT#2_S1
B18
A18 GND GND
PCI Express Slot 3/Lane 4 Connector X44
Pin Signal Pin Signal
B1
A1 PRSNT#1_S2 +12V
B2
A2 +12V +12V
B3
A3 +12V N.C.
B4
A4 GND GND
B5 SMB_CK
A5 N.C.
B6 SMB_DAT
A6 N.C.
B7
A7 N.C. GND
B8
A8 N.C. +3.3V
B9
A9 +3.3V N.C.
B10
A10 +3.3V +3.3V Standby
B11
A11 PCIE_RST# WAKE0#
B12
A12 GND N.C.
B13
A13 PCIE_CLKS2+ GND
B14
A14 PCIE_CLKS2‑ PCIE_TX4+
B15
A15 GND PCIE_TX4‑
B16
A16 PCIE_RX3+ GND
B17
A17 PCIE_RX3‑ PRSNT#2_S3
B18
A18 GND GND
Pin Signal
A1 PRSNT#1_S1
A2 +12V
A3 +12V
A4 GND
A5 N.C.
A6 N.C.
A7 N.C.
A8 N.C.
A9 +3.3V
A10 +3.3V
A11 PCIE_RST#
A12 GND
A13 PCIE_CLKS1+
A14 PCIE_CLKS1‑
A15 GND
A16 PCIE_RX1+
A17 PCIE_RX1‑
A18 GND
Pin Signal
A1 PRSNT#1_S3
A2 +12V
A3 +12V
A4 GND
A5 N.C.
A6 N.C.
A7 N.C.
A8 N.C.
A9 +3.3V
A10 +3.3V
A11 PCIE_RST#
A12 GND
A13 PCIE_CLKS3+
A14 PCIE_CLKS3‑
A15 GND
A16 PCIE_RX4+
A17 PCIE_RX4‑
A18 GND
CEVA_c_m10
Note
The JTAG pins are not connected
on the 4 PCI Express connectors
PCIe0 to PCIe3.
