Flat Panel Configuration Data
The flat panel configuration data (EPI extended EDID™ 1.3 file) for most common displays is included in the congatec COM Express™ CPU
module's system BIOS. The customer also has the possibility to store a customized EPI extended EDID™ 1.3 file in a serial EEPROM and then
connect it on the conga‑CEVAL (DIL 8 socket S2).
Note
Supported EEPROMs: 24C02, 24C04 and 24C16 at address A0h.
4.1.10

PCI Express x1 Connectors

The conga‑CEVAL is equipped with 4 x1 PCI Express Slots. The tables below describe the pinouts for each of these slots.
Copyright © 2012 congatec AG
PCIe Slot 0
(X17)
PCI Express
Lane 0
PCI Express
Lane 1
SM Bus
PCI Express
Lane 3
PCIe Slot 4
PCI Express
(X44)
Lane 4
PCIe Slot 1
(X18)
x1 PCI Express
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
PCIe Slot 3
(X45)
B12
B13
B14
B15
B16
B17
B18
CEVA_c_m10
EPI EEPROM
(S2)
Connector
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
