Technical Support

congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products
can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities and
drivers, which have been made available to assist you. If you still require assistance after visiting our website then contact our technical support
department by email at support@congatec.com
Terminology
Term
PCI Express (PCIe)
PCI Express Lane
x1, x2, x4, x16
ExpressCard
USB
SATA
AC '97/HDA
LPC
I²C Bus
SM Bus
SPI Bus
GBE
LVDS
SDVO
CRT
DDC
N.C.
N.A.
T.B.D.
Copyright © 2012 congatec AG
Description
Peripheral Component Interface Express – next‑generation high speed Serialized I/O bus
One PCI Express Lane is a set of 4 signals that contains one differential line for
transmitter and one differential line for receiver. Clocking information is embedded into the
data stream.
x1 refers to one PCI Express Lane of basic bandwidth; x2 to a collection of two PCI Express
Lanes; etc. Also referred to as x1, x2, x4 or x16 link.
A PCMCIA standard built on the latest USB 2.0 and PCI Express buses.
Universal Serial Bus
Serial AT Attachment: serial‑interface standard for hard disks
Audio CODEC (Coder-Decoder) / High Definition Audio
Low Pin‑Count Interface: a low speed interface used for peripheral circuits such as Super
I/O controllers, which typically combine legacy‑device support into a single IC.
Inter-Integrated Circuit Bus: is a simple two-wire bus with a software-defined protocol that
was developed to provide the communications link between integrated circuits in a system.
System Management Bus: is a popular derivative of the I²C-bus.
Serial Peripheral Bus
Gigabit Ethernet
Low‑Voltage Differential Signaling
Serial Digital Video Out is a proprietary technology introduced by Intel
video signaling interfaces to a system.
Cathode Ray Tube
Display Data Channel is an I²C bus interface between a display and a graphics adapter.
Not connected
Not available
To be determined
®
to add additional
