Connector Subsystems Rows A,B,C,D

4

Connector Pinout Rows A and B

4.1
Module Type 2 Connector Pinout Rows A and B
Table 5
Row A
Pin
A1 GND (FIXED)
GBE0_MDI3-
A2
GBE0_MDI3+
A3
GBE0_LINK100#
A4
GBE0_LINK1000#
A5
GBE0_MDI2-
A6
GBE0_MDI2+
A7
GBE0_LINK#
A8
GBE0_MDI1-
A9
GBE0_MDI1+
A10
A11 GND (FIXED)
GBE0_MDI0-
A12
GBE0_MDI0+
A13
GBE0_CTREF
A14
A15 SUS_S3#
A16 SATA0_TX+
A17 SATA0_TX‑
A18 SUS_S4#
A19 SATA0_RX+
A20 SATA0_RX‑
A21 GND (FIXED)
A22 SATA2_TX+
A23 SATA2_TX‑
A24 SUS_S5#
A25 SATA2_RX+
A26 SATA2_RX‑
BATLOW#
A27
A28 (S)ATA_ACT#
A29 AC/HDA_SYNC
A30 AC/HDA_RST#
A31 GND (FIXED)
AC/HDA_BITCLK
A32
A33 AC/HDA_SDOUT
Copyright © 2012 congatec AG
Row B Row A
Pin Pin
B1
GND (FIXED) A56 PCIE_TX4‑
B2 GBE0_ACT#
A57 GND
B3
LPC_FRAME# A58 PCIE_TX3+
B4
LPC_AD0 A59 PCIE_TX3‑
B5
LPC_AD1 A60 GND (FIXED)
B6
LPC_AD2 A61 PCIE_TX2+
B7
LPC_AD3 A62 PCIE_TX2‑
B8
LPC_DRQ0# A63 GPI1
B9
LPC_DRQ1# A64 PCIE_TX1+
B10
LPC_CLK A65 PCIE_TX1‑
B11
GND (FIXED) A66 GND
B12 PWRBTN#
A67 GPI2
B13 SMB_CK
A68 PCIE_TX0+
B14 SMB_DAT
A69 PCIE_TX0‑
B15 SMB_ALERT#
A70 GND (FIXED)
B16
SATA1_TX+ A71 LVDS_A0+
B17
SATA1_TX‑ A72 LVDS_A0‑
B18
SUS_STAT# A73 LVDS_A1+
B19
SATA1_RX+ A74 LVDS_A1‑
B20
SATA1_RX‑ A75 LVDS_A2+
B21
GND (FIXED) A76 LVDS_A2‑
B22
SATA3_TX+ A77 LVDS_VDD_EN
B23
SATA3_TX‑ A78 LVDS_A3+
B24
PWR_OK A79 LVDS_A3‑
B25
SATA3_RX+ A80 GND (FIXED)
B26
SATA3_RX‑ A81 LVDS_A_CK+
B27
WDT A82 LVDS_A_CK‑
B28
AC/HDA_SDIN2 A83 LVDS_I2C_CK
B29
AC/HDA_SDIN1 A84 LVDS_I2C_DAT
B30
AC/HDA_SDIN0 A85 GPI3
B31 KBD_RST#
GND (FIXED) A86
B32 KBD_A20GATE
SPKR A87
B33
I2C_CK A88 PCIE0_CK_REF+
Row B
Pin
B56
PCIE_RX4‑
B57
GPO2
B58
PCIE_RX3+
B59
PCIE_RX3‑
B60
GND (FIXED)
B61
PCIE_RX2+
B62
PCIE_RX2‑
B63
GPO3
B64
PCIE_RX1+
B65
PCIE_RX1‑
B66
WAKE0#
B67
WAKE1#
B68
PCIE_RX0+
B69
PCIE_RX0‑
B70
GND (FIXED)
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
B79 LVDS_BKLT_EN
B80
GND (FIXED)
B81 LVDS_B_CK+
B82 LVDS_B_CK-
B83 LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
CEVA_c_m10 18/47
