Next, check the printout results and specify the direction and position to be adjusted in
"Adjusting the Printing Position" (See the next item).

Adjusting the Printing Position

6
Next, check the printout results of the Printing Position Adjustment Print and specify
the direction and position to be adjusted.
The measurements of
This section describes the setting procedure for the following Printing Position
Adjustment Print printed with Cassette 1 specified, as an example.
6-64

Adjusting the Printing Position

The Printing Position Adjustment Print is printed as shown in the following. The
top of the output paper is the top of the Printing Position Adjustment Print.
Top
Feeding direction
printed on paper are as the following:
" "
10 mm
5 mm
*5 mm from each edge of paper
