Chapter 13
Electronics Compartment
13.3 Main Parts
Power Supply
(hidden)
CPU Board
84
This illustration shows the complete electronics compartment, but
with the Centronics interface board removed to improve the view
of the CPU board.
Ribbon Unwind Unit
Paper Rewind Motor
Ribbon Rewind Unit
Print Unit Stepper Motor
Intermec EasyCoder 601 XP – Service Manual Ed. 3
