8.7 Printhead, cont'd.
Intermec EasyCoder 601 XP – Service Manual Ed. 3
Description, cont'd.
The 12 dots/mm (304.8 dpi) printhead contains 1984 dots, which
give a maximum print width of 168 mm (6.61"). The same unit of
measure (dots) can be used both across and along the paper feed
direction.
Specifications:
Density 12 dots/mm
Print width 168.0 mm
Number of dots 1984
Dot size 0.083 mm
Chapter 8 Print Unit
(304.8 dpi)
(6.61")
(3.28 mils)
