Chapter 17 Troubleshooting
17.12 Printing Troubles,
cont'd.
156
Description:

Weak or missing printout of some dots.

Possible Causes and Suggested Remedies:
• Dirty printhead or pressing roller.
- Examine the printhead and the pressing roller for dust,
adhesive residue, or visible damage.
- Clean or replace.
• One or two missing dots.
- May be due to mechanical damage to the printhead. Try to
establish why such damage have occurred in order to prevent
future failures of this kind. (Hard foreign particles, electrostatic
discharge?).
- If the printer has been used for printing on less than full width
labels for some time, the pressing roller and possibly also the
printhead may have become worn from the outer paper edge.
This will show up when reverting to wider labels. Change the
pressing roller and possibly also the printhead.
• Preprinted ink has got stuck to the dot line.
- Avoid preprinted labels with ink that has a low melting point
(less than +225 ° C).
• Many dots, or a block of dots, are missing.
- The internal IC circuit of the printhead is probably damaged.
Replace the printhead.
Description:
Unexpected black printout (completely or partially).
Possible Causes and Suggested Remedies:
• Wrong printhead voltage.
- If the printer unexpectedly produces completely or partially
black printout, or prints a black line across the paper at
startup, regardless of label layout, check the printhead voltage
+24V. If too high, in the range of 40 to 50V, the trouble
probably originates from the power supply. Replace the power
supply unit.
- The printhead is most certainly damaged too and will also
need to be replaced.
Description:

Only first part of label printed.

Possible Causes and Suggested Remedies:
• Bad headlift sensor adjustment.
- Adjust as described in chapter 8.8.
Intermec EasyCoder 601 XP – Service Manual Ed. 3
