17.3 Printer Stops
Working after Startup
Intermec EasyCoder 601 XP – Service Manual Ed. 3
Description:
The printer stops working after a successful startup.
- The Power LED is lit.
- The keys, e.g. <Feed>, <Setup>, and <Print> keys, work
properly.
Possible Causes and Suggested Remedies:
• Communication problems?
- Refer to chapters 17.8 – 17.10.
• Printer malfunction?
- Check if the printer can print at all by trying to print some test
labels in the Test Mode.
Description:
The printer stops working after a successful startup.
- The Power LED is lit.
- There is no reaction on software commands.
- There is no reaction on any keys on the printer's keyboard.
Possible Causes and Suggested Remedies:
• The printer's main program has halted due to high external
disturbances from other electrical sources.
- Restart the printer and find out if there are disturbances
coming via the mains supply, via a communication channel, or
from other electrical appliances.
• CPU board failures.
- Refer to chapter 17.4.
• Power Supply Unit failures.
- Refer to chapter 17.5.
• Console errors.
- Refer to chapter 17.6.
Description:
The printer stops working after a successful startup.
- The Power LED is not lit.
Possible Causes and Suggested Remedies:
• Error in the supply of mains power to the printer.
- Refer to chapter 17.2.
• Faulty console, power LED or cabling between CPU board and
console.
- Refer to chapter 17.6.
Chapter 17 Troubleshooting
143
