1.2 Specifications

Printing:
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Media Width (max/min)
Print Length (max)
Internal Paper Roll Diameter (max)
Paper Roll Core Diameter
Ribbon Length (max)
Ribbon Width (max)
Print Directions
Modes of Operation
Tear Off
Peel Off
Cut Off
Firmware
Operating System
Smooth Fonts
Built-in scalable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x D x H)
Weight (excluding media & options)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMMs
Real-Time Clock
Power Supply
Mains Voltage
PFC Regulation
Maximum Power Consumption
Intermec EasyCoder 601 XP – Service Manual Ed. 3
Direct Thermal & Thermal Transfer
12 dots/mm (304.8 dots/inch)
100 – 225 mm/sec (4 – 8.85"/sec)
165.3 mm (6.49")
168 mm (6.61")/25.4 mm (1.00")
depends on free DRAM memory
205 mm (8")
38 – 40 mm (1.5"), with adapter 76 mm (3")
450 metres (1475 feet)
166 mm (6.54")
4
Yes
Optional
Optional
Fingerprint 7.31 incl. Intermec Direct Protocol
TrueDoc and TrueType fonts
15
36
Intermec Shell v. 4.4
335 x 482 x 238 mm (13.1 x 19.0 x 9.4")
15 kgs (33 lbs)
+5°C – +40° C (+41°F – +104° F)
20 – 80% non-condensing
32 bit RISC
1 – 3 (2 Mbytes each)
1 – 2 (1 x 4 Mbytes + 1 x ≤ 32 Mbytes)
Yes
>90 – <264 V AC, 45 – 65 Hz
IEC 61000-3-2
Continuous 175W; Peek ≈ 400W
Chapter 1 Models and Options
max. 2,730 mm/107,5"
With internal rewinder
With cutter
Unicode fonts
Std. 1 x 2 Mbytes
Std. 1 x 4 Mbytes
10+ years life
1
11
