8.2 Pressing Roller,
cont'd.
Stepper Motor
#T20 Torx Screw
Belt to
Pressing Roller
Pulley
Ball Bearing
Plastic Bearing
Spacer
Pressing Roller
Intermec EasyCoder 601 XP – Service Manual Ed. 3
In the illustration below, the upper parts of the print unit and the LSS
have been omitted to improve visibility.
#T20 Torx Screw
Plastic Bearing
Ball Bearing
Chapter 8
Belt to Ribbon Rewind Unit
Bracket
#T20 Torx Screw
Print Unit
43
