1.2

Specifications

Print Technique (std. model)
Print Technique (LinerLess model)
Print Resolution
Quick-mount Printhead
Maximum Print Width
Maximum Media Width
Smooth Fonts
Print Directions
Maximum Internal Paper Roll Diameter
Maximum Ribbon Length
Dimensions (W x D x H)
Weight (excluding media & options)
Ambient Operating Temperature
Humidity
Sound Emission Level
Microprocessor
Firmware
Label and Ribbon End Sensors
Mains Voltage
PFC Regulation
Maximum Power Consumption
Communications Interface Standard
Print Speed (tear off)
Print Speed (peel off/roll Ø 152 mm)
Print Speed (LTS enabled)
Bar Code Generators
On-board Flash EPROMs
On-Board RAM Memory
RS 232C Cable
Centronics Parallel Cable
Real Time Clock (RTC)
Label Taken Sensor (LTS)
Paper Cutter
Scalable Fonts
Memory Card Slot
Intermec EasyCoder 301 – Service Manual Ed. 3
Direct Thermal/Thermal Transfer
Direct Thermal on standard and Linerless media
8 dots/mm (203.2 dots/inch)
Yes
104 mm (4.09")
114 mm (4.5")
Yes
152 mm (6")
~200 M (656 feet)
235.5 x 352.9 x 169.3 mm (9.27 x 13.89 x 6.67 ")
4.7 kgs (10.3 lbs)
+5°C – +40°C (+41°F – +104°F)
20 –80% non-condensing
< 60 dB (A)
32 bit
Intermec EasyCoder 301 Direct Protocol 2.00
Yes
115/230VAC (+10%/-15%) 4/2A, 60/50Hz
IEC 61000-3-2
Stand-by 30W; Typical label 70W; Maximum 250W
1 x RS 232C Serial and 1 x Centronics Parallel
100 or 150 mm/sec (4 or 6 inches/sec)
100 mm/sec (4 inches/sec)
100 mm/sec (4 inches/sec)
2 x 512 kbytes
512 kbytes
Optional
Optional
Optional
Fitted
Optional
Built-in
1 PCMCIA 5V Type 3, or 2 PCMCIA 5V Type 1 or 2
Chapter 1 Models and Options
4
37
Build option
Recommended
F/W restricted
std. model only
7
