Programming
Subpages Commands (Cont.)

^SSH

^STG

The number of subpages that can be created is based on subpage size and limited
only to the system's available memory.
Using the same subpage set for multiple viewer buttons is not recommended. If you
have multiple subpage viewer buttons in a project that need to display the same
subpage list, using a unique set name for each is highly recommended. You can then
use the same address for each viewer button so that any subpage commands (like
^SSH) will apply to each set.
For more information on subpages and their use, please refer to the TPDesign4
online Help and the TPDesign4 Operation Reference Guide, available at
www.amx.com.
114
Subpage show command. This command will perform one of three different operations based on the
following conditions:
1. If the named subpage is hidden in the set associated with the viewer button it will be shown in the
anchor position.
2. If the named subpage is not present in the set it will be added to the set and shown in the anchor
position.
3. If the named subpage is already present in the set and is not hidden then the viewer button will move it
to the anchor position. The anchor position is the location on the
subpage viewer button specified by its weighting. This will either be left, center or right for horizontal
subpage viewer buttons or top, center or bottom for vertical subpage viewer buttons. Surrounding
subpages are relocated on the viewer button as needed to
accommodate the described operations.
Syntax:
"'^SSH-<vt addr range>,<name>,<optional position>,<optional time>'"
Variables:
vt addr range – Specifies the address(es) of the subpage viewer button to be modified.
name – Specifies the name of the subpage to be shown or added.
position – Specifies where to add (or show) the named subpage in the set with 0 representing the
beginning of the set. If this value is left out (or set to 65535) then the weighting value for the viewer
button is used to place the new subpage, i.e. left/top, center or right/bottom. When using the weighting
locations, set insertion positions can vary based on the current onscreen locations of existing
subpages.
time – Can range from 0 to 30 and represents tenths of a second. This is the amount of time used to
move the subpages around when subpages are added or removed from a button.
Subpage toggle command. If the named subpage is hidden, then this command activates a subpage
show command. If the named subpage is present, then a subpage hide command is activated. Parameter
definitions are the same as for the subpage show command.
Syntax:
"'^STG-<vt addr range>,<name>,<optional position>,<optional time>'"
Modero G4 Touch Panels - Configuration and Programming
