Management Agent

3.3.2 Management Blade

Within the blade server management system there are two management blades. One of them is active as the
master of the server management system. The other one is in standby mode to ensure the availability of the
system.
A number of parameters relating to the management blades is displayed to the user, showing their current values
(see next figure):
Figure 5: Management Blade menu
The following parameters are displayed:
Parameter
Management Blade Run Mode
Management Blade Status
Management Blade Manufacture
Management Blade Manufacture Date Date of manufacture for the management blade.
Management Blade Serial Number
Management Blade Product Name
Management Blade Model Name
Management Blade Hardware Version Hardware version of the management blade.
Management Blade Firmware Version Firmware version of the management blade.
Management LAN MAC Address
Service LAN MAC Address
Management Voltage Status
Management Voltage Maximum Value Maximum voltage of the MMB.
Management Voltage Minimum Value
Management Voltage Normal Value
Management Voltage Current Value
18
Description
Displays whether the management blade is run in master mode or slave
(standby) mode.
Health status of the management blade. A message will be displayed if
this status is disturbed.
Name of the manufacturer of the management blade.
Serial number of the management blade.
Product name of the management blade.
Name of the management blade model.
Physical address (MAC address) of the management LAN interface of
the MMB.
Physical address (MAC address) of the service LAN interface of the
MMB.
Status of the voltage supply of the MMB.
Minimum voltage of the MMB.
Standard voltage of the MMB.
Current voltage of the MMB.
ServerView BX900 Management Blade
Telnet Interface
