Telnet Interface

3.3.13 Power Consumption

This option is used to control the power consumption.
The menu for this option looks like this:
Figure 18: Power Consumption menu
The following parameters are displayed:
Parameter
Power Budget Control Threshold
Base Consumption
Total Consumption
Remaining
System Power Unit Status Table
System Power Unit Current Status Table
Server Blade Power Consumption Table
Server Blade Current Power Consumption
Table
Storage Blade Power Consumption Table
Storage Blade Current Power Consumption
Table
Connection Blade Power Consumption Table Displays the max. DC power consumption of each connection
Connection Blade Current Power
Consumption Table
Set Power Budget Control (no longer
available as of firmware version 5.32)
ServerView BX900 Management Blade
Description
Displays the max. DC power of the active power supply.
Power consumption of the base system. Includes one
management blade and 6 fan modules.
Current power consumption of the whole blade server system
(including server blades).
Difference between Power Budget Control Threshold and current
Total Consumption.
Displays the max. DC power and the voltage range of the power
supply units.
Displays the current status of each active PSU (power
consumption and voltage).
Displays the max. DC power consumption of each server blade.
Displays the current status of each active server blade (power
consumption).
Displays the max. DC power consumption of each storage blade.
Displays the current status of each active storage blade (power
consumption).
blade.
Displays the current status of each active connection blade (power
consumption).
Settings for power control (redundancy, dynamic, limit values, etc.)
– observe submenus.
Management Agent
