Ldap Authentication - Fujitsu PRIMERGY ServerView BX900 User Manual

Management Agent

3.3.14 LDAP Authentication

Use LDAP to login to the MMB through the Web-based or a CLI interface. The login syntax is: username@domain
(where username is an ASCII string of 1-256 bytes).
Figure 19: Active Directory Authentication menu
The following parameters are displayed:
Parameter
LDAP Authentication Enable
LDAP Type
LDAP over SSL
LDAP Server IP 1/2
Root Domain Name
User LDAP Base DN
User LDAP Department
Special User Account
Special User Password
34
Description
Enables/disables the LDAP functionality.
Selects the LDAP type (Microsoft's Active Directory, OpenLDAP, Novell's
eDirectory).
Selects whether LDAP is to use a secure SSL connection.
IP addresses of the primary and, if present, secondary LDAP server.
Name of the domain in which the user logs in.
Distinguished Name, a unique object name in LDAP directories.
"Department" of the user in the LDAP directory.
Needed to set up a connection to the LDAP server.
Password for setting up a connection to the LDAP server.
ServerView BX900 Management Blade
Telnet Interface
